Bidirectional High-Capacity DC Power Supply

PXB Series – 20kW model

PXB-20kW

3,500,000

  • High power density: 20 kW in 3U size
  • A single unit handles both power and regeneration
  • Rated output voltage 50 V/ 250 V/ 500 V/ 1000 V/ 1500 V
  • Select a model with an input voltage from 200 Vac (3-phase) or 400 Vac (3-phase)
  • Continuous operation at rated power at ambient temperature of 50°C(Excluding some models)
  • Up to 10 units (200 kW) can be operated in parallel
  • Equipped with touch panel display
  • LAN, USB, RS232C, external analog control (isolated type) standard
  • Regenerative function (on-site)
  • External control I/O is standard for both NPN and PNP type PLCs

LAN LXILAN LXIUKCA
ImageSKUOutput Power [W]標準価格WEBかんたんお見積り
双方向直流電源PXB20K-5020kW30mVrms3,500,000
(税込:3,850,000
双方向直流電源PXB20K-25020kW125mVrms3,500,000
(税込:3,850,000
双方向直流電源PXB20K-50020kW250mVrms3,500,000
(税込:3,850,000
双方向直流電源PXB20K-100020kW500mVrms3,500,000
(税込:3,850,000
双方向直流電源PXB20K-150020kW750mVrms3,500,000
(税込:3,850,000
SKU: PXB-20kW

ModelOutputRipple noisePower fluctuationLoad variationRise time / Fall timeInput current
CVCC*1Rated powerCV(rms)CVCCCVCCCVCCAC 208 V (3-phase 3-wire) /
480 V (3-phase 3-wire)*2
Rise timeFall timeRise time
(Short-circuit) (TYP)
Fall time
(Short-circuit) (TYP)
PXB20K-500 V to 50 V-800 A to +800 A20 kW30 mV±10 mV±1600 mA±40 mV±1600 mA10ms5ms80A/40A
PXB20K-2500 V to 250 V-200 A to +200 A125 mV±50 mV±400 mA±125 mV±400 mA
PXB20K-5000 V to 500 V-120 A to +120 A250 mV±100 mV±240 mA±250 mV±240 mA
PXB20K-10000 V to 1000 V-60 A to +60 A500 mV±200 mV±120 mA±500 mV±120 mA
PXB20K-15000 V to 1500 V-30 A to +30 A750 mV±300 mV±60 mA±750 mV±60 mA

*1 The minimum voltage at which the maximum Sink is possible is 6 % of the rated voltage for the PXB20K-50, and 2 % of the rated voltage for other models. *2 Select type at purchase. Switching not possible.
