CUSTOM-MADE TEST & CONTROL SYSTEM

CUSTOM-MADE TEST / CONTROL SYSTEM

The Customized/System solution realized with Kikusui strength having both technologies, Measurement & Power Supply.

To meet with the various application of individual customer’s request, Kikusui offers to provide most suitable design of the system not limited to standard product items.

We have designed and delivered various custom products and systems to the wide range of customers from the field of R&D to the Production, QA, Service in the industry of Automotive, Telecommunication, components devices to apply for such testing requirement of evaluation , compliance with standard which were required based on the system of Electronic loads and Power Supplies.

In case if you require any special application of the testing system which were not perfectly found in our standard specification of product line, please ask for your local sales re pre se nt at ive, we surely would provide our best proposal to meet your request by combining our established engineering of technology in Measuring instr uments and Power Supplies at our original point of view.

Field of business industry/Application

Controlling various devices and the Power Supply (Electronic Load) System for the reliability evaluation testing.

  • AutomobileVarious Electronic devices
  • Electronic ComponentsPDP, LCD panel
  • TelecommunicationSwitching box, terminal station, equipped device for the satellite
  • R&D, MedicalAccelerator Control
  • Power Supply TesterHigh Voltage, Large Capacity, Multi Output
  • OthersChemical synthesis, metal plating

Charge-Discharge test system for the evaluation test for various batteries.

  • EV(Electric Vehicle) related applicationHigh performance battery for vehicle equipped motor, measuring for power efficiency
  • Fuel Cell related applicationSingle Cell, Stack Cell, I/V Characteristics test
  • Medical related applicationBattery for small health equipment
  • Telecommunication related applicationCell phone, batter y for the terminal devices
  • Material related applicationAn Electrode, Chemical synthesis

Test system for the Standard/Regulation Compliance application.

  • Harmonic Current measuring
  • Flicker Test
  • Immunity Test
  • Automated Hipot, Insulation Test

Please ask for our sales representative even if your requirement may not be complied with following categories.

Special order items

Inrush current power supply (For vehicle electronic parts test)

This is a constant voltage generating device that secures a rush load current operation region (with time restriction) in order to test loads such as starter motors, lamps, etc. that transiently require a lot of current. Addition of the output impedance variable function that changes the output voltage according to the output current is also available. (The photograph shows an example of DC20V – 300A (1000A at peak)model.

ラッシュカレント電源

Charge-discharge power system (For acral parts)

This is a model whose rated current has been changed as requested based on a catalog model Charge-discharge tester PFX2000. Charge-discharge test under various conditions of PFX2000 is available. (The photograph shows an example of DC5V – 50A 1CH model.)

充放電電源装置

We also provide sample connection jigs for quantitative and reproducible tests.

For cylindrical or square batteries PFX治具
For polymer or laminate batteries PFX治具

300W x 5ch constant current electronic load system(For vehicle electronic parts test)

This is a multichannel electronic load system containing 5 channels of the electric load part of the 300W rated current per device. In this device, the constant current mode is the only operation mode as a special order specification in the pursuit of usability.

5Ch定電流電子負荷装置

Uninterruptible DC power system (For radio communication equipment)

This is an equipment that maintains DC output even when failures occur in the commercial power supply. This equipment is for social infrastructures, etc., which always need a stable DC output. (The photograph shows an example of DC13.8V – 16A model (over 5A – 2h at power outage).)

無停電直流電源装置

Modified products

We accept orders for the various modified products based on the products in the catalog. Modified products that can be designed to meet specific application by adding your custom specifications to the products in our catalog, which have technology and reliability that have been built based on the standard specitications.

  • Addition/change of various signal input and output functions
  • Addition/change of operation system
  • Change of operation rating, etc….

For information about modifying the products in the catalog, please feel free to contact us.



Test system

We provide an exclusive test system that is made only for you and includes application software required as a test system and a rack as well as the equipment. Kikusui, which is famous for its “measurement and power supply,” supports your high technology with our unique custom-made test system.

Harmonic/Flicker Analyzer system
(LIN1020JF mounting system)

高周波フリッカ試験システム

Charge-discharge test system
(PFX2021 x20units mounting system)

充放電試験システム (PFX2021×20台実装システム)

Prearcing characteristic test system
(PLZ-4W mounting system)

ヒューズ溶断特性評価システム (PLZ-4W実装システム)

32kW x 3ch DC power system
(PAT-T mounting system)

32kW×3ch直流電源システム (PAT-T実装システム)

DC power system
(PWR800L x10units mounting system)

直流電源システム (PWR800L×10台実装システム)
