Harmonic/Flicker Analyzer – KHA Series
In addition to the standards and functions supported by the well-received KHA1000, the KHA3000 supports IEC 61000-3-12 (harmonics) and IEC 61000-3-11 (flicker and voltage changes), which are required for harmonic and flicker compliance testing of single- and three-phase equipment rated above 16 A. The unit can perform high-accuracy, simultaneous three-phase measurements on its own, at up to 40 A per phase.
Along with real-time displays that offer an operating experience similar to an oscilloscope or FFT analyzer, the KHA3000 also provides real-time compliance judgment. It can perform compliance evaluation and generate test reports without a PC. For example, you can take the unit to a large piece of equipment, conduct the test nearby, and obtain a pass/fail result on the spot. This can dramatically reduce the time required for compliance testing.
The KHA3000 also supports measurements on single-phase equipment and compliance testing for equipment rated at 16 A or less. A compliance test system can be configured easily by combining the unit with an AC power source and a line impedance network. In addition, the KHA Series supports three measurement technology standards, allowing a single unit to measure both components that include interharmonics and, as before, integer harmonics only.
