Firmware Updater
VER 2.22
2021-10-28
FPGA2.01.0001
New Feature
Fixed a problem of failing to start at certain ambient temperatures. (IFC2.21.0005: No Change)
VER 2.21
2020-10-23
IFC2.21.0005
New Feature
Option81 has been added to the Request packet of DHCP.
VER 2.21
2020-10-23
FPGA2.00.0005
Resolved issues
The problem of characters "nan" appearing in the measurement has been fixed.
Resolved issues
The problem where the integrated value was reset when executing the sequence even under a not resetting condition has been fixed.
VER 2.20
2020-2-07
IFC2.20.0000
New Feature
Added an alarm that goes off when an invalid slave unit is connected.
VER 2.20
2020-2-07
FPGA2.00.0002
Resolved issues
Fixed the issue of malfunction caused by the parallel connection of units with imperfect grounding.
VER 2.11
2019-9-12
IFC2.11.0000
New Feature
Improved to support USB memory devices used for saving or exporting sequence programs.
New Feature
Added a new function to set a load state after sequence completion.
New Feature
Added "Cutoff" to the post-trigger source of the sequence function.
New Feature
Added a reset key (*RST) in "SYSTEM > SCPI" to allow immediate reset.
Updated
Moved the menu to set the synchronization of sequence start from "SOURCE > More" to "SEQUENCE > More".
Updated
Changed the factory default setting for soft start time from OFF to 500 μs.
Updated
Changed the factory default setting for response speed in ARB mode from OFF to 500 μs.
Updated
Changed the signal pulse width of output from the TRIG OUT connector in pulse operation or sine operation from 1 μs to 10 μs.
VER 2.11
2019-9-12
FPGA2.00.0001
New Feature
Improved to support the PLZ-5WH2 series to be connected as a slave unit when the PLZ-5WH series is used as a master unit.
